Description
Features:
- Easy Installation
- No physical connection to the AC line that is being monitored
- Magnetically coupled by passing supply line through protruding Current Transformer
- 8-Pin, Plug-in
The CMB Series relay is used to detect the presence of AC. When the monitored current exceeds the trip point for longer than 30 milliseconds, the internal relay energizes. When the monitored current drops below the trip point for longer than 0.5 seconds, the internal relay de-energizes. The Delay-on-Release is incorporated to prevent nuisance tripping caused by momentary dips in the load line. An External CT may be used to extend the range of the Current Monitor.
For more information, please see Data Sheet
| Control Voltage | 24VAC; 50/60 Hz, 24VDC |
| Trip Points | 10 Amps, Fixed |
| Ac Input Current | Up to 50 Amps |
| Power | 3 Watts (Approximately) |
| Consumption Response Time |
|
| Life Expectancy |
|
| Duty Cycle | Continuous |
| Temperature Rating |
|
| Enclosure | Lexan Dust Cover; 8-Pin plug-in |
| Weight | 6 oz |
