Description
Automatic Timing & Controls Diversified, VCFP96M, Multifunction/Power Meter
Features:
- 3Ø True RMS (Voltage/Current)
- 3Ø Power (Active, Reactive, Apparent), Energy (Active, Reactive, Apparent)
- Programmable CT/PT Primary/Secondary
- CT Polarity Error Detection
- Variable Pulse Width Selection
- Single Phase Network with Phase Selection
- Modbus RTU Communication (RS485)
- Neutral Current Measurement
- THD Up to 31st Level
- Single Pulse Output/Demand Phase Sequence Detection
The VCFP96M is a complete single phase and three phase digital metering system suitable for low, medium and high voltage control panels, gensets, load banks, building management systems and power management systems. The VCFP96M can be used on single phase, three phase three wire as well as three phase four wire balanced or unbalanced systems. The six easy to access front control keys are used for scrolling up or down through the parameters being measured and displayed such as voltage, current, power factor, power (active, reactive, apparent), energy and frequency. Output specifications include pulse output and RS485 Modbus RTU communication protocol compatible with PC, PLC, RTU, data loggers and SCADA programs.
For more information, please see Data Sheet
| Input | |
| Electrical Connection |
|
| Input Voltage Range |
|
| Input Current Range | Nominal 5A AC (Min-11mA, Max-6A) |
| Frequency | 45 to 65Hz |
| Display Scrolling | Automatic / Manual (Programmable) |
| Power Consumption | 8VA Max |
| Display Reset | Programmable (For energy) |
| Resolution |
|
| Accuracy |
|
| Memory Retention | 10 years (For energy) |
| Measuring Parameters |
|
| Output | |
| Pulse Output |
|
| Communication Interface and Protocol | RS485 and MODBUS RTU |
| Communication Address | 1 to 255 |
| Transmission Mode | Half duplex |
| Transmission Distance | 500 meter maximum |
| Transmission Speed | 300, 600, 1200, 2400, 4800, 9600, 19200 (in bps) |
| Parity | None, Odd, Even |
| Stop Bits | 1 or 2 |
| Response Time | 100 ms (max and independent of baud rate) |
| Auxiliary Supply | |
| Supply Voltage | 100 to 240V AC, -15% +12%, 50/60 Hz, (±5%) |
| Settable Parameters | |
| CT Primary | 1/5A to 10kA (Programmable for any value) |
| CT Secondary | 1/5A (Programmable) |
| PT Primary | 100V to 500kV (Programmable for any value) |
| PT Secondary | 100V to 500V (Programmable for any value) |
| Environmental Specifications | |
| Temperature |
|
| Humidity (Non-Condensing) | Up to 85% RH |
| Mechanical Specifications | |
| Mounting | Panel mount |
| Weight | 318 gms |
