BWI Eagle, 36-10100-DC, Air-Eagle SR Plus 2.4GHz Transmitter, Single Dry Contact Input, 9-36VDC Powered
Features:
- The AIR-EAGLE SR PLUS TX is an R.F. transmitter capable of sending a single dry contact input command to an Air-Eagle SR Receiver from up to 600 feet away.
- Any number of transmitters and receivers can be combined to create a medium-range remote control system that operates hazardous or hard-to-reach electrical apparatus from safe, convenient locations.
- This unit has eight user-selectable network frequencies to allow multiple systems to operate simultaneously in the same area without interference.
For more information, please see Data Sheet
| Power Input | 9 – 36 VDC, 5 W |
| Battery Type | (2) 1.5V lithium or alkaline each, size AA, to equal 3.0VDC nominal. |
| RF Output Power | 60 mW |
| Transmitter Range | Up to 600 Feet |
| RF Networks | Eight Independent Frequencies |
| Digital Addresses | Sixteen |
| Antenna Connection | TNC Female |
| Enclosure | Polycarbonate NEMA 4, 12, 13 – IP66 |
| Operating Temperature | -40° F to +185° F |
| Weight | Approx 2 lbs |
