Description
TSR Organiser : Aft Organiser for diverting lines from clutches and jammers.
- 20mm alloy sheaves
- All rotating sheaves with plain bearings
- Fixed Sheaves can be inserted in the organiser to further increase deflection loads
- Alloy top rails
- Modular design and assembly – Sheaves can be moved to any spacing
- Tulip shaped design reduces friction from vertical defection
- Simple inserting and removal of endless lines
- Central shaft designed to spread load through laminate
- Titanium parts available to further reduce weight
Our Part # SPI-TSR20L-4 | Mfr. Part # TSR20L/4
Sheave Diameter: 20mm
Number of Sheaves: 4
Sheave Max Load: 1500kg
Total Combined Max Sheave Load: 3000kg
30° Deflected Rope Load: 3000kg
60° Deflected Rope Load: 1500kg
Weight: 535g
Line Max Diameter: 13mm
Fasteners: 4 x M8
Overall Length: 142mm
